Sigrid is a member of the B6 class 4-4-0 push-pull tank engine who was mainly intended for suburban passenger trains. The class was a fast development of the B5 class and quickly proved their worth on fast, short-range trains. B6.2 14 "Sigrid" was rebuilt with superheater elements and piston valves during the early 1910s to prolong both her and her siblings working life.Dimensions
UIC: 2’B h2t
Length of Buffers: 7 825 mm
Width: 2 300 mm
Height: 3 405 mm
Wheelbase: 5 240 mm
Rigid wheelbase: 4 495 mm
Gauge: 1 000 mm
Driving wheel Ø: 1 400 mm
Running wheel Ø: 800 mm
Cylinders Ø: 400 mm
Stroke: 480 mm
Boiler
Working pressure: 12 Bar
Boiler Ø: 1 150 mm
Length: 4 000 mm
Grate area: 0,712 m²
Evaporative surface: 56,0 m²
Steam output: 2 240 kg/h
Coal: 1 185 kg/h at 65% efficiency
Speed and Power
Tractive effort: 52,5 kN
Top speed: 110 km/h
Maximum effect 8 km/h: 118 kW
Max load (2% incline): 220 ton
Fuel
Coal cap: 1,14 m³ = 1 260 kg
Water cap: 2 310 l
Weight
10 740 kg/driving axle
Engine weight: 32 220 kg
