Artwork I made of some aircraft programs from around the world that were cancelled for some reason or another:-----
Lockheed CL-400 Suntan - Designed as a potential replacement for the U-2 Dragonlady, the CL-400 would have been a reconnaissance aircraft capable of traveling at Mach 2.5. Research and development of the design took place from 1956 to 1958. It was to be powered by liquid hydrogen and fly at an altitude of 30,000 meters (98,500 feet).
Reason(s) for cancellation: Insufficient range, monetary issues, fuel issues.
-----
Kyūshū J7W1 Shinden - An unusual pusher-prop configuration, the Shinden was designed to be an agile interceptor capable of attacking B-29 Superfortress bomber aircraft. With a top speed of 469 miles per hour, it would have been one of the fastest aircraft at the time. Two prototypes were built, one of which took flight. Production never occured.
Reason(s) for cancellation: Ending of WWII.
-----
IAI Lavi - An Israeli multi-role fighter jet, the Lavi featured all-moving canards, delta wings, ventral fins, and a single afterburning turbofan. It possessed fly-by-wire controls, and advanced avionics including self-analysis equipment. Two prototypes were constructed and flown.
Reason(s) for cancellation: Insufficient finances, pressure from the US government, questions of cost-effectiveness.
-----
Sukhoi T-4 Sotka - The T-4 was a Russian aircraft resembling a hybrid between the XB-70 Valkyrie and Concorde. It was designed as an interceptor and reconnaissance aircraft capable of reaching Mach 3. The nose of the aircraft was mobile and would cover the windscreen during flight, but was lowered during take-off and landing. A periscope was used to see during flight. Four prototypes were built.
Reason(s) for cancellation: Budgetary compromises to buy fighters instead of T-4s.
-----
SNECMA C.450 Coléoptère - A vertical take-off and landing (VTOL) fighter jet, the Coléoptère featured a unique annular wing in place of a conventional wing. A single turbojet powered the aircraft. Due to the aircraft's design it could only take-off and land vertically and conventional take-off and landings were not possible.
Reason(s) for cancellation: Prototype crashed during a test flight.
-----
Focke-Wulf Triebflügel - Possibly one of the most unique aircraft designs of all time, the Triebflügel was designed to be a VTOL interceptor. A ramjet-powered, free-spinning rotor assembly would have provided lift for the aircraft as well as directional thrust. The tail would have provided pitch and yaw control. The aircraft only made it to the stage of wind-tunnel models.
Reason(s) for cancellation: Ending of WWII.
